Scott Patron 10 2027 Obsidian Red/Carbon Black
4276328563008
SCOTT PATRON 10 2027 OBSIDIAN RED/CARBON BLACK
The Scott Patron 10 2027 Obsidian Red/Carbon Black is an electric mountain bike for off-road rides and trails. Its assistance system uses the Bosch Performance Line CX (BDU384Y) motor and a 800 Wh battery. The 1x12 drivetrain lets you adjust your pedalling to the route.
FEATURES:
- Frame: Carbon Main Frame, alloy SST-CST, Integrated Suspension Technology, Virtual 4 Link kinematic, Adjustable head angle, Syncros Cable Integration System, Bosch Smart System, UDH Interface, 12x148mm with 55mm Chainline, Bosch PowerMore Ready
- Fork: Fox 36 Perf. Air, eOptimized, Grip, 3Pos Microadj, Reb Adj, QR Axle 15x110mm axle, tapered steerer
- Rear Shock: Fox Float Performance EVOL, LSR, 2P Lever
- Rear Derailleur: SRAM GX Eagle AXS Transmission 12 Speed, Wireless Electronic Shift System
- Shifters: SRAM AXS Rocker Pod Controller
- Crankset: SRAM GX Eagle, alloy
- Cassette/Rear Sprocket: SRAM GX Eagle XS-1275 Transmission, 10-52T
- Chain/Belt: SRAM GX Eagle Transmission
- Front Brake: Shimano XT BR-M8220 ABS Pro 4-Piston/Shimano RT-6B750, 220mm
- Rear Brake: Shimano XT BR-M8220 ABS Pro 4-Piston/Shimano RT-6B750, 200mm
- Front Tire: Maxxis Forekaster 29x2.6", 60TPI Foldable, Tubeless Ready, EXO 3C maxx Terra
- Rear Tire: Maxxis Forekaster 29x2.6", 60TPI Foldable, Tubeless Ready, EXO 3C maxx Terra
- Handlebar: Syncros Hixon 1.5 alloy 7050, back sweep 8°, 780mm
- Stem: Syncros AM 1.5, Syncros Cable Integration System, 4° rise, 7050 alloy, 31.8mm, 1 1/8"
- Seatpost: Syncros dropper post SP-M300-AL2, +RAD drop adjust, 31.6mm
- Saddle: Syncros Tofino-E 1.5, Titanium rails
- Motor: Bosch Performance Line CX (BDU384Y)
- Battery: Bosch PowerTube 800Wh
- Display: Bosch Kiox 300
- Charger: Bosch 4A Charger 230V
- Drivetrain: 1x12
- Approximate Weight: 24.4 kg
- Headset: Syncros - Acros Angle adjust & Cable Routing HS System, Stainless steel, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
- Front Hub: Formula DC-611, 15x110mm
- Rear Hub: Formula EHL-148S, Boost 148x12mm
- Rims: Alex Rims MD30 Disc 29" 32H, Black, Tubeless Ready
- Chain Guide: e*thirteen, e*spec Slider
- Grips: Syncros Performance XC Lock-On
Specifications may change without notice.
Pairs well with
Livraisons rapides et sécurisées
Conseils personnalisés
Garantie de 2 ans
Retours gérés en toute simplicité
Scott Patron 10 2027 Obsidian Red/Carbon Black
If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, within 24 hours on weekdays.
-
Shipping Information
Use this text to answer questions in as much detail as possible for your customers.
-
Customer Support
Use this text to answer questions in as much detail as possible for your customers.
-
FAQ’s
Use this text to answer questions in as much detail as possible for your customers.
-
Contact Us
Use this text to answer questions in as much detail as possible for your customers.
Product details
General
- Year
- 2027
- Gender
- Unisex
- Family
- Bicis
- Wheel size
- 29
Frame
- Frame
- Carbono Triángulo principal, Aluminio SST-CST, Tecnología de suspensión integrada, cinemática virtual de cuatro bieletas, Ángulo de dirección ajustable, Syncros Cable Integration System, Bosch Smart System, interfaz UDH, 12x148mm con 55 mm Línea de cadena, Bosch PowerMore Ready
- Fork
- Fox 36 Perf. Aire, eOptimized, Grip, 3Pos Microadj, Reb Adj, QR Eje 15x110mm Eje, Tubo de dirección cónico
- Rear shock
- Fox Float Performance EVOL, LSR, 2P Lever
- Frame material
- Carbono
- Headset
- Syncros - Acros ajuste del ángulo & sistema de dirección y guiado de cables, Acero inoxidable, +-0.6° ajuste del ángulo de dirección, ZS56/28.6 – ZS56/40 MTB
Cockpit
- Handlebars
- Syncros Hixon 1.5 Aluminio 7050, Retroceso 8°, 780mm
- Stem
- Syncros AM 1.5, Syncros Cable Integration System, 4° Elevación, 7050 Aluminio, 31.8mm, 1 1/8"
- Grips
- Syncros Performance XC Lock-On
Brakes
- Front brake
- Shimano XT BR-M8220 ABS Pro 4-Pistones/Shimano RT-6B750, 220mm
- Rear brake
- Shimano XT BR-M8220 ABS Pro 4-Pistones/Shimano RT-6B750, 200mm
Saddle
- Saddle
- Syncros Tofino-E 1.5, Titanium rails
- Seatpost
- Syncros tija telescópica SP-M300-AL2, +RAD drop adjust, 31.6mm
Drivetrain
- Shift levers
- SRAM AXS Rocker Pod Controller
- Rear derailleur
- SRAM GX Eagle AXS Transmission 12s, Sistema de cambio electrónico inalámbrico
- Cassette
- SRAM GX Eagle XS-1275 Transmission, 10-52t
- Chain
- SRAM GX Eagle Transmission
- Crankarms
- SRAM GX Eagle, Aluminio
- Chainrings
- SRAM XX Direct Mount Bosch 34t
- Speeds
- 1x12
- Chain guide
- e*thirteen, e*spec Slider
Wheels
- Front tire
- Maxxis Forekaster 29x2.6", 60TPI plegable, compatible con montaje tubeless, EXO 3C maxx Terra
- Rear tire
- Maxxis Forekaster 29x2.6", 60TPI plegable, compatible con montaje tubeless, EXO 3C maxx Terra
- Rims
- Alex Rims MD30 Disc 29" 32H, Negro, compatible con montaje tubeless
- Front hub
- Formula DC-611, 15x110mm
- Rear hub
- Formula EHL-148S, Boost 148x12mm
eBike Components
- Motor
- Bosch Performance Line CX (BDU384Y)
- Battery
- Bosch PowerTube 800Wh
- Charger
- Bosch 4A cargador 230V
- Screen
- Bosch Kiox 300
*Images are for illustrative purposes only and may differ from the final product. Colours may vary depending on the screen used.
*Please note that technical specifications may be changed without prior notice by the manufacturer.
